LMC-H型脈沖濾筒除塵器采用上 的托里特沉流式技術。濾筒采用斜插式安裝,既能良好的除塵效果,又能方便濾筒的換。具有體積小,,外形美觀,維護方便等優點,是解決產生懸浮塵粒的各種工作環境的佳選擇。廣泛適用于電子、制藥、化工、冶煉、煙草、機械鑄造、水泥建材、糧食飼料加工等行業的工業粉塵處理。
LMC-H型脈沖濾筒除塵器規格參數表:
型號 | 濾筒數量 | 過濾面積 (m2) | 處理風量 (m3/h) | 外形尺寸(mm) | 設備阻力(Pa) | 清灰用氣源壓力(MPa) |
LMC-H2-8 | 8 | 80 | 2400~4800 | 1008X2600X3100 | 800~1500 | 0.4~0.6 |
LMC-H2-16 | 16 | 160 | 4800~9600 | 2008X2600X3100 | ||
LMC-H2-24 | 24 | 240 | 7200~14400 | 3008X2600X3100 | ||
LMC-H2-32 | 32 | 320 | 9600~28800 | 4008X2600X3100 | ||
LMC-H2-40 | 40 | 400 | 12000~19200 | 5008X2600X3100 | ||
LMC-H2-48 | 48 | 480 | 14400~28800 | 6008X2600X3100 | ||
LMC-H2-56 | 56 | 560 | 16800~33600 | 7008X2600X3100 | ||
LMC-H2-64 | 64 | 640 | 19200~38400 | 8008X2600X3100 | ||
LMC-H3-12 | 12 | 120 | 3600~7200 | 1008X2600X3600 | ||
LMC-H3-24 | 24 | 240 | 7200~14400 | 2008X2600X3600 | ||
LMC-H3-36 | 36 | 360 | 10800~21600 | 3008X2600X3600 | ||
LMC-H3-48 | 48 | 480 | 14400~28800 | 4008X2600X3600 | ||
LMC-H3-60 | 60 | 600 | 18000~36000 | 5008X2600X3600 | ||
LMC-H3-72 | 72 | 720 | 21600~43200 | 6008X2600X3600 | ||
LMC-H3-84 | 84 | 840 | 25200~50400 | 7008X2600X3600 | ||
LMC-H3-96 | 96 | 960 | 28800~57600 | 8008X2600X3600 | ||
LMC-H4-16 | 16 | 160 | 4800~9600 | 1008X2600X4100 | ||
LMC-H4-32 | 32 | 320 | 9600~19200 | 2008X2600X4100 | ||
LMC-H4-48 | 48 | 480 | 14400~28800 | 3008X2600X4100 | ||
LMC-H4-64 | 64 | 640 | 19200~38400 | 4008X2600X4100 | ||
LMC-H4-80 | 80 | 800 | 24000~48000 | 5008X2600X4100 | ||
LMC-H4-96 | 96 | 960 | 28800~57600 | 6008X2600X4100 | ||
LMC-H4-112 | 112 | 1120 | 33600~67200 | 7008X2600X4100 | ||
LMC-H4-128 | 128 | 1280 | 38400~76800 | 8008X2600X4100 |
